| Place of Origin: | China |
| Brand Name: | Saiko |
| Certification: | CE |
| Model Number: | SK20 |
| Minimum Order Quantity: | 20PCS |
|---|---|
| Price: | Negotiation |
| Delivery Time: | 5-8 days |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 20000PCS/Month |
| Voltage: | 230VAC | Type: | Heating |
|---|---|---|---|
| Certificate: | CE | Protection Grade: | TP20 |
| High Light: | electric underfloor heating thermostat,underfloor heating programmable thermostat |
||
SK70.XX Electronic Heating Thermostat
Summary
The RTC70.XX is used for 2-position control with on/off output for the control the temperature by means of an NTC sensor placed externally or internally in the thermostat.
The thermostat acquires the room temperature with its built-in sensor or floor sensor,and the heating contact will close when the room temperature falls below the selected set point.
Application
For the control of warm-water(floor)heating systems and direct electric heating systems used in commercial bulding.Residential buildings,Light industrial buildings......
Features
LED Indicator is light when heating is on
With manual switch and knob for easy operation
On/Off control output for heating device
Technical Parameters
Temperature setting range:4~45°C
Working voltage:230VAC± 10%,50/60HZ
Power consumption:5W
Switching differential:±0.5K
Ambient temperature:-5~50°C )
Protective housing:IP20
Housing material:Self-extinguishing PC
Floor sensor:Rubber-thermoplastic NTC sensor.
Cable length is 3m
