Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System

Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System

    • Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System
    • Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System
    • Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System
    • Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System
  • Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System

    Product Details:

    Place of Origin: Jiangsu
    Brand Name: Saiko
    Certification: CE
    Model Number: SK99

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PCS
    Price: Negotiation
    Packaging Details: 1pc/inner box, 50pcs/carton
    Delivery Time: 10 WORKDAYS
    Payment Terms: T/T, Western Union
    Supply Ability: 2000PCS/WEEK
    Contact Now
    Detailed Product Description
    Type: Floor Heating Systems Voltage: 85-265V
    Setting Range: 5-90℃ (can Adjust To 35-90 ℃) External Limitation: 5...60℃(Factory Setting: 35℃)
    Housing Material: Anti-flammable PC IP Rating: IP20
    Color: Black
    High Light:

    touch screen room thermostat

    ,

    touch screen heating thermostat

    Modern Touch Screen Design smart thermostat for floor heating system

    • This SK99 Touch Screen Thermostat is a Touch Screen Thermostat, which is designed for electric floor heating system or water heating system. Using 4.0 inch color touch LCD display, the working status can be easily understood.
    • With six modes, the system can work according to your desired pre-set temperature conveniently. And the 5+1+1 days programmable function, which is easy-to-program on/off settings per day.
    • Simple regulation which sends On/Off commands to the heating system according to a pre-selected temperature variation. The thermostat control algorithm includes an anticipation function which reduces the discrepancy between the thermostat reading and the temperature at the centre of the room.
    • Choose from sensor setting: Ambient (built-in sensor)- to control the air temperature; Floor - to control the temperature using the floor probe; Ambient and Floor - to control the ambient air, and show floor temperature by using the floor probe.

    Programming



    Choice of 7 day, 5/2 day programmable ;
    non-programmable (installer selectable);
    6 time and 4 temperature settings every day;
    pre-programmed or personalized schedule;
    Energy saving up to 33%;



    Display
    Large, touchscreen display;
    European standard installation box;
    White lighted display for easier low-light viewing;
    Larger, easy-to-read character size;

    Intuitive menu-driven set-up, programming and operation,
    Permanent program retention during power loss;
    Setpoint temperature limited range capable;
    Enhanced touchscreen security prevents tampering.
    Temperature display resolution: 0.5 C;

    Smarts Modern Touch Screen Thermostat 85-265V For Floor Heating System
    A / AF/ F models all in one
    Combination of 3 models;
    A - Air only, with built-in sensor;
    F - Floor only,controls floor temperature;
    AF - Controls air temperature with ability to limit the
    floor temperature



    Specifications



    * Power supply: 230VAC (120VAC optional)
    * Inputs: 2 x NTC10K temperature sensors
    * Output: 1 x switch relay(R1),max 3500watts
    * Ambient temperature: 0 °C [+32 °F] ~ +45 °C [+113 °F]
    * Operating RH: 0~95% (non condensing)
    * Dimensions: 86mm x 86mm x14mm
    * Backlight life: 5,000 hours



    Features

    • Adjustable Comfor Mode, Economy Mode, Party Mode, Holiday Mode and Program Made Control
    • 5+1+1 Weekly Programmable for Energry Saving operation
    • External and Internal Sensor
    • Clock and Date Display
    • Temperature Clibration
    • Over-heating Protection
    • On/ off Control Output for Heating Device
    • Symbol indicator when heating is on
    • Temperacture limitation fuction
    • Hgihly Reliable Single-chip Microcontroller used
    • Black, silver, White Apperance

    Packing details
    1pc/inner box, 50pcs/carton
    Carton size: 51x22x36cm
