Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption

Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption

    • Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption
    • Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption
    • Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption
    • Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption
    • Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption
  • Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption

    Product Details:

    Place of Origin: Jiangsu
    Brand Name: Saiko
    Certification: CE
    Model Number: SK91

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: negotiation
    Packaging Details: 64PCS/CTN (CTN SIZE:435*395*290mm)
    Delivery Time: 10 work days
    Payment Terms: T/T, Western Union,Paypal
    Supply Ability: 2000pcs/week
    Contact Now
    Detailed Product Description
    Name: SK91 Type: Floor Heating System
    Color: Silver Current Lode: 16A
    Protective Housing: IP20 Ambient Temperature: -5~50℃
    High Light:

    electric underfloor heating thermostat

    ,

    underfloor heating room thermostat

    Electric Touch Screen Programmable Thermostat



    SK91 Touch Screen Period Programming Thermostat Weekly circulation, it is possible to set 6 periods called events each day with corresponding pre-set temperatures, also you can select "period control mode" or "manual mode" according to your individual requirements. The thermostat is recommended for the control of electric heating devices or on/off valve actuator used in water-based heating systems.



    Technical Parameters



    Voltage AC220-240VAC 50/60HZ
    Power Consumption 2VA
    Setting Range 5°C~90°C
    Limitation Range 5°C~60°C( factory setting: 35°C)
    Accuracy of temperature measurement  0.5~10 Adjustable, factory setting±1ºC
    Ambient temperature -5~50ºC
    Protective housing IP20
    Housing material  anti-flammable PC





    User operation

    1) Power key " "

    You can turn on/off the thermostat by pressing this key. Also you can confirm and exit by pressing " "key when you have completed the setting of every parameter.

    2) The increase key" "and the decrease key" "

    In the period control mode or comfort mode , when you press the increase/decrease key once, alternate display stops in the bottom right region and the value of the pre-set temperature will increase/decrease 1 . It will recover the alternate display

    with no operation for 3 seconds.

    3) Time setting key "

    you can adjust the time and week by pressing the key once. If it is pressed, the hour bit flashes. Then you can press " " key and " "key to change its value. When you cmplete the setting of hour bit, you can press this key to confirm and continue the setting of minute bit and week bit sequently. After the completion of time, you can press" "to confirm and exit.

    4) Mode selection key" M "

    You can select period control mode or comfort mode by pressing the key. If you press this key and hold for 3 seconds, you can enter the mode of period

    programming.

    5) Locking " " and unlocking

    When you press " "and" "at the same time and hold for 3 seconds, the thermostat will be locked/unlocked. When it is locked, no operation can be carried out until it is unlocked.



    Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption



    Touch Screen Heated Floor Thermostat Programmable 2VA Power Consumption



    Trade Information



    Trade Terms FOB,CIF,CFR
    Payment terms T/T,Western union,Paypal
    Payment conditions 100% in advance/30% deposit in advance,70% balance before shipping.
    Delivery time 3-15 working days
    Packing Neutral carton
    Shipping By sea,by air and by express delivery
